Appendix 1 Relationship between the Time Axis Setting, Record Length, and Sample Rate
Relationship between the Main Channel Sample Rate and the Sub
Channel Sample Rates of the CAN Bus Monitor Module
Main Channel
Sample Rate
(S/s)
Number of Sub Channels
1 2 3 to 4 5 to 8 9 to 16 17 to 32
1
33 to 60
1
Maximum Sample Rate
100 k 100 k 100 k 100 k 100 k 100 k 100 k
100 M 100 k 100 k 100 k 100 k 100 k 100 k 100 k
50 M 100 k 100 k 100 k 100 k 100 k 100 k 100 k
20 M 100 k 100 k 100 k 100 k 100 k 100 k 100 k
10 M 100 k 100 k 100 k 100 k 100 k 100 k 100 k
5 M 100 k 100 k 100 k 100 k 100 k 100 k 50 k
2 M 100 k 100 k 100 k 100 k 100 k 50 k 20 k
1 M 100 k 100 k 100 k 100 k 50 k 20 k 10 k
500 k 100 k 100 k 100 k 50 k 20 k 10 k 5 k
200 k 100 k 100 k 50 k 20 k 10 k 5 k 2 k
100 k 100 k 50 k 20 k 10 k 5 k 2 k 1 k
50 k 50 k 10 k 10 k 5 k 2 k 1 k 500
20 k 20 k 10 k 5 k 2 k 1 k 500 200
10 k 10 k 5 k 2 k 1 k 500 200 100
5 k 5 k 1 k 1 k 500 200 100 50
2 k 2 k 1 k 500 200 100 50 20
1 k 1 k 500 200 100 50 20 10
500 500 100 100 50 20 10 5
200 200 100 50 20 10 5 2
100 100 50 20 10 5 2 1
50 50 10 10 5 2 1 -
20 20 10 5 2 1 - -
10 10 5 2 1 - - -
5 5 1 1 - - - -
1
This features covers firmware versions 1.30 and later of the DL850/D
L850V.

YOKOGAWA DL850 ScopeCorder Specifications

General

Maximum Sampling Rate	100 MS/s
Power Supply	100 to 240 VAC, 50/60 Hz
Resolution	16-bit
Operating Temperature	5 to 40°C
Bandwidth	20 MHz
Input Types	Voltage, Temperature, Strain, Acceleration, Frequency, Logic, Current
Interfaces	Ethernet, USB, GP-IB
Trigger Modes	Edge, Window, Pattern
Number of Channels	Up to 128 (with multiple input modules)
Memory Capacity	Up to 2 G points (with /M4 option)
