YOKOGAWA DL850 ScopeCorder User Manual

App-16
IM DL850-03EN
Relationship between the Main Channel Sample Rate and the Sub
Channel Sample Rates of the CAN & LIN Bus Monitor Module
Main Channel
Sample Rate
(S/s)
Number of Sub Channels
1 2 3 to 4 5 to 8 9 to 16 17 to 32
1
33 to 60
1
Maximum Sample Rate
100 k 100 k 100 k 100 k 100 k 100 k 100 k
100 M 100 k 100 k 100 k 100 k 100 k 100 k 100 k
50 M 100 k 100 k 100 k 100 k 100 k 100 k 100 k
20 M 100 k 100 k 100 k 100 k 100 k 100 k 100 k
10 M 100 k 100 k 100 k 100 k 100 k 100 k 100 k
5 M 100 k 100 k 100 k 100 k 100 k 100 k 50 k
2 M 100 k 100 k 100 k 100 k 100 k 50 k 20 k
1 M 100 k 100 k 100 k 100 k 50 k 20 k 10 k
500 k 100 k 100 k 100 k 50 k 20 k 10 k 5 k
200 k 100 k 100 k 50 k 20 k 10 k 5 k 2 k
100 k 100 k 50 k 20 k 10 k 5 k 2 k 1 k
50 k 50 k 10 k 10 k 5 k 2 k 1 k 500
20 k 20 k 10 k 5 k 2 k 1 k 500 200
10 k 10 k 5 k 2 k 1 k 500 200 100
5 k 5 k 1 k 1 k 500 200 100 50
2 k 2 k 1 k 500 200 100 50 20
1 k 1 k 500 200 100 50 20 10
500 500 100 100 50 20 10 5
200 200 100 50 20 10 5 2
100 100 50 20 10 5 2 1
50 50 10 10 5 2 1 -
20 20 10 5 2 1 - -
10 10 5 2 1 - - -
5 5 1 1 - - - -
Appendix 1 Relationship between the Time Axis Setting, Record Length, and Sample Rate

YOKOGAWA DL850 ScopeCorder Specifications

General

Maximum Sampling Rate	100 MS/s
Power Supply	100 to 240 VAC, 50/60 Hz
Resolution	16-bit
Operating Temperature	5 to 40°C
Bandwidth	20 MHz
Input Types	Voltage, Temperature, Strain, Acceleration, Frequency, Logic, Current
Interfaces	Ethernet, USB, GP-IB
Trigger Modes	Edge, Window, Pattern
Number of Channels	Up to 128 (with multiple input modules)
Memory Capacity	Up to 2 G points (with /M4 option)
