YOKOGAWA DL850 ScopeCorder User Manual

App-22
IM DL850-03EN
Operation Key Soft Key Setting
GO/NO-GO
Mode OFF
Logic AND
ActCondition Fail
Sequence Continue
Acquisition Count Infinite
Remote OFF
Beep OFF
Print Image OFF
Save Waveform OFF
Save Image OFF
Send Mail OFF
Time Range1 –5.00 div
Time Range2 5.00 div
HISTORY
Display Mode 1 Record
Select Record 0
Start Record 0
End Record Oldest number
Search Mode OFF
MATH
Mode OFF
Select Math Trace 1
Opeartion:Math1 OFF
Opeartion:Math2 OFF
Opeartion:Math3 OFF
Opeartion:Math4 OFF
Opeartion:Math5 OFF
Opeartion:Math6 OFF
Opeartion:Math7 OFF
Opeartion:Math8 OFF
Scaling Mode Auto
Start Point –5.00 div
End Point 5.00 div
FFT Points 1 k
Window Hanning
FFT
Display OFF
Trace CH1
Start Point –5.00 div
FFT Points 1 k
Window Hanning
Vert. Scale Mode Auto
Main Ratio 50%
Window Layout Side
Horiz. Axis Log Hz
ZOOM
Display (Zoom1) ON
Display (Zoom2) OFF
Position 0.00 div
Main Ratio 50%
Window Layout Side
Format Zoom1 Main
Operation Key Soft Key Setting
SEARCH
Type Edge
Edge
Trace CH1
Level 0.0 V
Polarity Rising
Hysteresis
Count 1
Result Window Zoom1
Pattern No. No Match
Event
Select Number 1
Result Window Zoom1
Select Event Capture
Logic Pattern
Trace Installation channel
Bit Setting X
Result Window Zoom1
Pattern No. No Match
Start Point –5.00 div
End Point 5.00 div
Time
Absolute Time Current date and
time
Result Window Zoom1
PRINT MENU
Print To Builtin
UTILITY
System Config
Date/Time
Display ON
Format Year/Month/Day
Time Synchro
Time
Synchro
OFF
IRIG Format A
Modulation AM
Impedance 50
Language
Menu English
Message English
LCD
Auto OFF OFF
Auto OFF
Time
1 min
Brightness 3
Storage Manager
Media HD
USB Keyboard English
USB Function TMC
Remote Ctrl
Device USB
USB Function TMC
Network
TCP/IP
DHCP ON
DNS Auto
FTP/Web Server
User Name anonymous
TimeOut(s) 1800
TimeOut (s) 15
Appendix 3 Default Values

YOKOGAWA DL850 ScopeCorder Specifications

General

Maximum Sampling Rate	100 MS/s
Power Supply	100 to 240 VAC, 50/60 Hz
Resolution	16-bit
Operating Temperature	5 to 40°C
Bandwidth	20 MHz
Input Types	Voltage, Temperature, Strain, Acceleration, Frequency, Logic, Current
Interfaces	Ethernet, USB, GP-IB
Trigger Modes	Edge, Window, Pattern
Number of Channels	Up to 128 (with multiple input modules)
Memory Capacity	Up to 2 G points (with /M4 option)
