Explanation
The DL9000 returns GO/NO-GO results depending on whether or not the automatically
measured waveform parameters (see section 10.2 for details) are within the range that
you set.
GO/NO-GO Condition Number
You can choose to configure a GO/NO-GO condition from 1 to 4.
GO/NO-GO Target Parameters
The DL9000 bases GO/NO-GO determination on the waveform parameters and
calculated values measured in all modes.
GO/NO-GO Determination Range
You set the range by specifying its maximum and minimum values.
GO/NO-GO Determination Condition
• IN: The DL9000 returns a no-go result when the waveform parameters are in the set
range.
• OUT
: The DL9000 returns a no-go result when the waveform parameters are outside
of the set range.
• X: GO/NO-GO determination does not take place.
Note
In the following circumstances, the Statistic soft key appears in the soft key menu in step 2 (when
you press the Condition soft key), and the Area/Calc soft keys do not appear in step 7.
• When the waveform parameter mode is Cycle Statistics (PARAM > Mode = Cycle Statistics;
see section 10.3)
Press the Statistic soft key and choose one of the following statistical operations.
Max (maximum value), Min (minimum value), Mean (mean value),
σ
(standard deviation)
7.13 Setting Waveform Parameter GO/NO-GO Determination Conditions
To Next Page
