5-25
IM MV1000-01E
Screen Operations
1
2
3
4
5
6
7
8
9
10
11
12
13
App
Index
5.
To save a specified file, select it with the cursor.
Cursor
(Move with the arrow keys)
6.
Press DISP/ENTER to open the display selection menu.
M.SAMPLE SAVE: Saves all manually sampled data.
ALL SAVE: Saves all data.
TIME DISPLAY: Switches between displaying the times of the first and
last data entries in the file and displaying the file name.
CHANGE DATA KIND: Switches between display
data and event data.
REPORT SAVE: Saves all report data.
SELECT SAVE: Saves the selected file.
7.
Use the up and down arrow keys to select SELECT SAVE, ALL SAVE, M.
SAMPLE SAVE, or REPORT SAVE.
* If you are using a CF card and USB flash memory, the message “Which media do you want
save to?” appears. Use the arrow keys to select which medium you want to save to, and
press DISP/ENTER.
The measured data is saved.
ALL SAVE Progress Indicator
If you select ALL SAVE
*
from the memory summary, a progress indicator for the ALL
SAVE operation will appear.
* This function saves all of the data in the internal memory to a CF card or USB flash memory
device.
5.9 Using the Memory Summary
