6.5 Changing Channel Display Colors
This section explains how to change channel display colors. The color settings are
applied to the trend and bar graph displays.
Display
Press MENU and then select Menu tab > Meas channel > Color.
Settings
• Group of channel
Select the target channels.
• Color
To change a color, select from the following 24 colors.
Red, green, blue, blue violet, brown, orange, yellow-green, light blue, violet, gray, lime,
cyan, dark blue, yellow, light gray, purple, black, pink, light brown, light green, dark
gray, olive, dark cyan, and spring green
