6.11 Changing the Bar Graph Display Method
This section explains how to change the bar graph display method.
For an explanation of the bar graph display, see section 1.4.
Display
• Display Direction
MV1000
Press MENU and then select Menu tab > Display > Bar graph.
MV2000
Press MENU and then select Menu tab > Display > Trend, Bar graph, LCD,
Monitor.
• Base Position and the Number of Scale Divisions
MV1000
Press MENU and then select Menu tab > Meas channel > Bar graph.
