YOKOGAWA MVAdvanced MV1000 Series - 6.3 Setting the Secondary Trend Interval

6-4
IM MV1000-01E
6.3 Setting the Secondary Trend Interval
This section explains how to switch the trend interval to the secondary interval during
memory sampling. You can configure the MV to automatically write a message when the
trend interval is switched.
For an explanation of these functions, see section 1.4.
Display
• Switching the Trend Interval and Writing a Message (when using the
secondary trend interval)
MV1000
Press MENU and then select Menu tab > Basic setting mode > Environment tab >
View, Message.
MV2000
Press MENU and then select Menu tab > Basic setting mode > Environment tab >
View, Message, Input, Alarm.
• Second interval [/div]
MV1000
Press MENU and then select Menu tab > Display > Trend.
