10.3 Displaying Computation Channels
You can assign computation channels to groups and display them just like measurement
channels.
For an explanation of these functions, see section 1.9.
Display
• Color
Press MENU and then select Menu tab > Math channel > Color.
• Showing the Zone Display, Scale Display, and Bar Graph display
MV1000
Press MENU and then select Menu tab > Math channel > Zone, Scale or Bar graph.
MV2000
Press MENU and then select Menu tab > Math channel > Zone, Scale, Bar graph.
