YOKOGAWA MVAdvanced MV1000 Series User Manual

13-14
IM MV1000-01E
13.6 General Specifications
Construction
Item Specifications
Material Case: Aluminum plate (MV2000), metal plate (MV1000)
Bezel: Polycarbonate
Color Case: Smoke blue (Munsell 4.1PB6.0/4.5 or equivalent)
Bezel: Light gray (Munsell 5.2PB8.2/1.0 or equivalent)
External dimensions MV1000: 189(W) × 177(H) × 253(D) mm, 189(W) × 177(H) × 259(D) mm
*1
, 189(W) × 186(H) ×
259(D) mm
*2
MV2000: 307(W) × 273(H) × 254(D) mm , 307(W) × 273(H) × 260(D) mm
*1
*1 With clamp terminals (input terminal suffix code is -1) or pulse inputs (/PM1 option)
*2 Rechargeable battery model (power supply suffix code is -3)
Weight MV1004, MV1006, MV1012: Approx. 3.3 kg, Approx. 4.5 kg
*1
, MV1008, MV1024: Approx. 3.5 kg,
Approx. 4.7 kg
*1
MV2008, MV2020: Approx. 5.3 kg, MV2010: Approx. 5.2 kg, MV2030: Approx. 5.5
kg, MV2040, MV2048: Approx. 5.6 kg excluding options
*1 Rechargeable battery model (power supply suffix code is -3)
Normal Operating Conditions
Item Specifications
Supply voltage 90 to 132, 180 to 250 VAC
Power supply frequency 50 Hz ± 2%, 60 Hz ± 2%
Ambient temperature 0 to 40°C, 10 to 40°C (Rechargeable battery model (power supply suffix code is -3))
Ambient humidity 20 to 80%RH (at 5 to 40°C)
Vibration 10 to 60 Hz, 0.2 m/s
2
Shock Not allowed
Magnetic field 400 A/m or less (DC and 50/60 Hz)
External noise Normal mode (50/60 Hz)
DC voltage The peak value including the signal must be less than 1.2 times the measuring range.
Thermocouple The peak value including the signal must be less than 1.2 times the measuring thermal
electromotive force.
RTD 50 mV or less
Common mode noise 250 VACrms or less for all ranges (50/60 Hz)
Maximum noise voltage between channels
250 VACrms (50/60 Hz) or less
Installation position Horizontal
You can tilt the MV by bringing the front legs out.
Warm-up time At least 30 minutes after power-on
Installation location Indoors
Operating altitude 2000 m or less
Input Terminal (input terminal suffix code -1)
Item Specifications
Type Clamp terminal
Attachable and detachable for each channel
Recommended wire size: 0.08 mm
2
to 1.5 mm
2
(AWG28 to 16)
Input Terminal (input terminal suffix code -2)
Item Specifications
Type M4 screw
