YOKOGAWA MVAdvanced MV1000 Series User Manual

13-15
IM MV1000-01E
Specifications
1
2
3
4
5
6
7
8
9
10
11
12
13
App
Index
Power Supply (Power supply suffix code -1)
Item Specifications
Rated supply voltage 100 to 240 VAC
Supply voltage range 90 to 132, 180 to 264 VAC
Rated power supply frequency 50 Hz or 60 Hz
Power consumption MV1000/MV2000 Supply voltage LCD backl
ight off
Normal Maximum
MV1000 100 VAC 15 VA 30 VA 45 VA
240 VAC 25 VA 40 VA 60 VA
MV2000 100 VAC 28 VA 40 VA 65 VA
240 VAC 38 VA 54 VA 90 VA
Allowable interruption time Less than 1 cycle of the power supply frequency
Power Supply (Power supply suffix code -2)
Item Specifications
Rated supply voltage 12 VDC/24 VDC
Supply voltage range 10.0 to 28.8 VDC
Power consumption MV1000/MV2000 Supply voltage LCD backl
ight off Normal Maximum
MV1000 12 VDC 7 VA 14 VA 24 VA
24 VDC 7 VA 14 VA 23 VA
MV2000 12 VDC 9 VA 18 VA 35 VA
24 VDC 9 VA 18 VA 33 VA
Miscellaneous A/D converter integration time: Fixed to 20 ms (50 Hz) if set to Auto
When using the AC adapter
Rated supply voltage 100 to 240 VAC
Supply voltage range 90 to 264 VAC
Rated power supply frequency 50 Hz or 60 Hz
Maximum input power consumption
MV1000: 60 VA, MV2000: 90 VA
Rated power supply frequency 48 to 62 Hz
Power consumption MV1000/MV2000 Supply voltage LCD backl
ight off
Normal Maximum
MV1000 100 VAC 15 VA 30 VA 45 VA
240 VAC 25 VA 40 VA 60 VA
MV2000 100 VAC 28 VA 40 VA 65 VA
240 VAC 38 VA 54 VA 90 VA
Dielectric strength 1500 VAC (50/60 Hz) for one minute between the AC adapter power supply terminal and
earth
Miscellaneous A/D converter integration time: Fixed to 20 ms (50 Hz) if set to Auto
Power Supply (Power supply suffix code -3)
Item Specifications
Battery drive mode
When the AC adapter and the battery are used in combination, the AC adapter is the primary power supply.
Charging function Charge mode by connecting the AC adapter, whether the power switch is ON or OFF.
Charge time Approx. 2.5 hours
Number of times chargeable Approx. 300 times (depends on operating conditions)
LED display ALARM LED : Lights when the battery voltage drops
CHARGE LED : Lights while charging, blinks when fully charged.
When us
ing the
AC adapter
Rated supply voltage 100 to 240 VAC
Supply voltage range 90 to 264 VAC
Rated power supply frequency 50 Hz or 60 Hz
Power supply frequency 48 to 62 Hz
Rated AC adapter output
voltage
19.5 V (18.0 to 20.0 V)
Maximum AC adapter output
current
4.7 A
13.6 General Specifications
