YOKOGAWA MVAdvanced MV1000 Series - Chapter 4 Measurement and Recording; 4.1 Setting the Recording Conditions of Measured Data

4-1
IM MV1000-01E
Measurement and Recording
1
2
3
4
5
6
7
8
9
10
11
12
13
App
Index
Chapter 4 Measurement and Recording
4.1 Setting the Recording Conditions of Measured
Data
This section explains how to select a method for recording measured data.
For an explanation of the recording function, see section 1.5.
Display
• Data Type
Press MENU and then select Menu tab > Basic setting mode > A/D, Memory.
• Measurement Channels
MV1000
Press MENU and then select > Menu tab > Meas channel > Tag, Memory, Delay.
MV2000
Press MENU and then select > Menu tab > Meas channel > Tag, Memory sample,
Alarm delay.
• Trend/Storage interval and Save interval (for display data)
Press MENU and then select > Menu tab > Data save > Disp data.
