7.2 Setting Timers
You can set timers on the events of the event action function. Timers are also used in
TLOG computation.
For an explanation of the event action function, see section 7.1.
Display
Press MENU and then select Menu tab > Timer, Event action > Timer.
• When relative time is selected • When absolute time is selected
Settings
You cannot change these settings during memory sampling or computation.
• Timer No.
You can set four timers (1 to 4).
When Using a Relative Timer
• Mode
Select Relative.
• Interval
Set the interval in the range of 00:01 (1 minute) to 24:00 (24 hours).
• Reset at Math Start
On: Resets the timer when computation is started. The resetting of the timer is not
considered a timeout. Even if the timer is used as an event, the action is not executed.
When Using an Absolute Timer
• Mode
Select Absolute.
• Interval
Set the interval from within the range of available settings (1min to 24h).
• Ref. time
Set the time in the range of hour 0 to hour 23.
To Next Page
