13.7 External Dimensions
MV1000
If not specified, the tolerance is ±3 %. However, in cases of less than 10 mm, the tolerance is ±0.3 mm.
REAR VIEW
189
259
(10.20)
162.4
(7.44)
(6.39)
191
11°
232
177
(7.52)
(9.13)
(6.97)
TM
TM
POWER
Unit : mm
(approx. inch)
