13-21
IM MV1000-01E
Specifications
1
2
3
4
5
6
7
8
9
10
11
12
13
App
Index
With vertical stand attached
189
305
177
POWER
DISP/
ENTER
If not specified, the tolerance is ±3 %. However, in cases of less than 10 mm, the tolerance is ±0.3 mm.
Unit : mm
(approx. inch)
(7.44)(12.0)
(6.97)
13.7 External Dimensions
