YOKOGAWA MVAdvanced MV1000 Series User Manual

13-22
IM MV1000-01E
With an EIA/ANSI-compliant rack
Dimension of oval holes
Rack mounting fittings Rack mounting fittings
Spacer
Spacer
Rack mounting screw cramp
(left and right, two each)
Use the included M3 screw
Appropriate tightning torque:
0.6N·m
(Deistance between mounting holes)
Panel
30 228
482.6±1
465
177
5.95
31.75
101.6 31.75
10.3
13.7
482.6
7
If not specified, the tolerance is ±3 %. However, in cases of less than 10 mm, the tolerance is ±0.3 mm.
Unit : mm
(approx. inch)
(8.98)(1.18)
(0.41)
(0.54)
(19.0)
(19.0)
(18.3)
(6.97)
(4.00) (1.25)(0.23)
Rechargeable Battery Model (Power supply suffix code is -3)
DC INPUT
19.5VDC 50VA MAX
259
(10.20)
166.5
(6.55)
26.5
(1.04)
186
(7.32)
189
(7.44)
REAR VIEW
POWER
DISP/
ENTER
ALARM CHARGE
10Base-T USB RS-422-A/485
FG SG SDB SDA RDB RDA
If not specified, the tolerance is ±3 %. However, in cases of less than 10 mm, the tolerance is ±0.3 mm.
Unit : mm
(approx. inch)
13.7 External Dimensions
