MV2000
Unit : mm
(approx. inch)
REAR VIEW
307
(12.09)
281
(11.06)
260
(10.24)
334
(13.15)
273
(10.75)
283
(11.14)
10.5°
TM
TM
If not specified, the tolerance is ±3 %. However, in cases of less than 10 mm, the tolerance is ±0.3 mm.
13.7 External Dimensions
