YOKOGAWA MVAdvanced MV1000 Series User Manual

13-24
IM MV1000-01E
With an EIA/ANSI-compliant rack
Dimensions of oval holes
Rack
mounting
fittings
Rack
mounting
fittings
Spacer
Spacer
Rack mounting screw cramp
(left and right, two each)
Use the included M4 screw
Appropriate tightning torque:
0.9 N·m
(Distance between mounting holes)
Panel
36.5
217
482.6±1
465
310
37.3
44.45
146.05
44.45
10.3
13.7
7
482.6
(19.0)
(19.0)
(18.31)
(1.44)
(8.54)
(0.54)
(0.41)
(12.2)
(5.75) (1.75)(1.75)(1.47)
If not specified, the tolerance is ±3 %. However, in cases of less than 10 mm, the tolerance is ±0.3 mm.
Unit : mm
(approx. inch)
13.7 External Dimensions
