6.7 Displaying a Scale on the Trend Display
This section explains how to display a scale on the trend display.
For an explanation of the trend display, see section 1.4.
Display
• Scale Division, Scale Division
MV1000
Press MENU and then select Menu tab > Meas channel > Zone, Scale.
MV2000
Press MENU and then select Menu tab > Meas channel > Zone, Scale, Bar graph.
• Scale Digit, Value Indicator
MV1000
Press MENU select Menu tab > Display > Trend.
