• Alarm mark
Displays marks that indicate the values of the high and low limit alarms, delay high
and low limit alarms, and difference high and low limit alarms. These settings are
shared with the bar graph display.
• Alarm mark > Mark kind
Setting Description Mark
Alarm Displays green marks under normal conditions and red
marks when alarms are activated.
Fixed Displays marks in fixed colors.
• Alarm mark > Indicate on Scale
To display alarm value marks, select On.
• Alarm mark > Alarm mark color > Alarm 1, Alarm 2, Alarm 3, and
Alarm 4
If Mark kind is set to Fixed, specify the alarm value mark colors.
• Color scale band
Displays a color band on the scale for a specied section of the measurement range.
These settings are shared with the bar graph display.
• Color scale band > Band area
Setting Description
In Displays a color band for the area inside the range.
Out Displays a color band for the area outside the range.
Off Disables this function.
• Color scale band > Color
Set a color.
• Color scale band > Display position > Lower, Upper
Specify the display position. Specify a value within the span or scale range.
Lower: The lower limit of the area.
Upper: The upper limit of the area.
6.8 Displaying Alarm Value Marks and Color Scale Bands
