• Changing the Display Selection Menu/Submenu Positions
1.
Press the arrow keys to select a menu item.
2.
Press the Select soft key.
The menu item is enclosed in a red frame.
3.
Press the arrow keys to select the destination.
4.
Press the Transfer soft key.
The menu item moves to the selected position.
• Showing/Hiding Separators
1.
Press the arrow keys to select a menu item.
2.
Press the Separate soft key.
A separator (line) is displayed between the current item and the next lower item.
If the separator is already showing, pressing the key hides it.
You can set up to three separators in the display selection menu and each sub-
menu.
• Description of the Display Selection Menu and Submenu Items
Items with an asterisk are set to Hide by default.
Display Selection
Menu
Submenu Reference Section
Trend GROUP 1 to GROUP 10
1
/GROUP 36
2
Section 5.2/6.12
ALL CHANNEL/GROUP CHANNEL Section 5.2/6.13
AUTO ZONE ON/OFF Section 5.2
SCALE ON/OFF Section 5.2/6.12
FINE GRID ON/OFF Section 5.2
DIGITAL ON/OFF Section 5.2/6.12
MESSAGE DISP 1/2 Section 5.2
* TREND SPACE ON/OFF Sections 5.2 and 6.12
AUTO SCROLL ON/OFF Sections 5.2 and 6.12
EXPAND
2
Section 5.11
TREND HISTORY GROUP 1 to GROUP 10
1
/GROUP 36
2
Section 5.3
DIGITAL GROUP 1 to GROUP 10
1
/GROUP 36
2
Section 5.2
AUTO SCROLL ON/OFF Section 5.2
EXPAND
2
Section 5.11
BAR GROUP 1 to GROUP 10
1
/GROUP 36
2
Section 5.2
AUTO SCROLL ON/OFF Section 5.2
EXPAND
2
Section 5.11
OVERVIEW CURSOR ON/OFF Section 5.4
JUMP TO ALM SUM Section 5.4
JUMP TO TREND Section 5.4
* JUMP TO DIGITAL Section 5.4
* JUMP TO BAR Section 5.4
EXPAND
2
Section 5.11
6.17 Changing the Function Menu and the Display Selection Menu
