3-4
IM MV1000-01E
• Range > Type
Input type when Mode is set to Delta or Scale. See the explanation of Mode.
• Range > Range
These are specic input settings.
Setting Input Type Note Setting Input Type Note
20mV –20,000 mV to 20.000 mVDC Standard R Type R Standard
60mV –60.00 mV to 60.00 mVDC S Type S
200mV –200.00 mV to 200.00 mVDC B Type B
2V –2.0000 V to 2.0000 VDC K Type K
6V –6.000 V to 6.000 VDC E Type E
20V –20.000 V to 20.000 VDC J Type J
50V –50.00 V to 50.00 VDC T Type T
Pt Pt100 N Type N
JPt JPt100 W Type W
Level ON/OFF (Voltage) L Type L
Contact ON/OFF (Contact) U Type U
1-5V 0.800 V to 5.200 V WRe Type WRe
Sett
ing
Input Type Note Setting
Input Type Note
K Kp vs Au7Fe /N3 option Cu1 Cu10 (GE) /N1 option
PLATI PLATINEL Cu2 Cu10 (L&N)
PR PR40-20 Cu3 Cu10 (WEED)
NiMo NiNiMo Cu4 Cu10 (BAILEY)
W/WRe W/WRe26 Cu5 Cu10: a = 0.00392 at 20°C
N2 Type N (AWG14) Cu6 Cu10: a = 0.00393 at 20°C
Pt50 Pt50 Cu25 Cu25: a = 0.00425 at 0°C
Ni1 Ni100 (SAMA)
Ni2 Ni100 (DIN)
Ni3 Ni120
J263 J263*B
Cu53 Cu53
Cu100 Cu100: a = 0.00425 at 0°C
Pt25 Pt25
• Range > Span Lower,Span Upper
The input range. The range of available settings will be displayed on the screen.
Note
• You cannot set Span Lower and Span Upper to the same value.
• When Mode is set to 1-5V or Sqrt, you can only set Span Lower to a value that is less than
Span Upper.
• Range > Scale Lower, Scale Upper
The input range after unit conversion.
You can set the scale values to anywhere from –30000 to 30000. The decimal place is
determined by the Scale Lower setting. It can be set to the following positions: X.XXXX,
XX.XXX, XXX.XX, XXXX.X, or XXXXX.
Note
• The MV converts the measured value to a value within the range set by the Scale Lower
and Scale Upper values with their decimal points removed. For example, if you set the scale
range to –5 to 5, the range of converted values will be 10, but if you set the scale range to –5.0
to 5.0, the range of converted values will be 100. The resolution of values converted within
the range of 10 will be less than that of values converted within the range of 100. For a clear
view, set the scale values so that the range of converted values is greater than 100.
• You cannot set Scale Lower and Scale Upper to the same value.
• When Mode is set to 1-5V or Sqrt, you can only set Scale Lower to a value that is less than
Scale Upper.
3.3 Setting the Input Range
