3-28
IM WT5000-02EN
3.8 Custom Display
You can register up to five screen configurations in advance and use them as you like.
► “Custom Display (CUSTOM)” in the features guide
This section explains operating procedures using the following setup methods.
• Procedure Using the Setup Menu (see chapter 1)
• Procedure Using the Menu Icons (see page iii)
• Procedure Using the Keys (other than SETUP) (see section 1.2 in IM WT5000-03EN)
Depending on the measurement mode, the settings may be different from the description in this
section, the settings may be invalid, or the settings may not be configurable. For details, see the
features guide.
Procedure Using the Setup Menu
1.
Tap the Setup icon , or press MENU under SETUP.
2.
Tap the Computation/Output tab. A computation and output settings overview screen appears.
Pressing ESC closes the overview screen.
Setting the Display Format (Display)
3.
Tap Display.
A display format setting screen appears.
Computation/Output tab
Display button
Select from the five registered custom
screens.
Custom Screen Registration
Set the display to Custom.
Note
You can also display the computation/output settings overview screen by moving the cursor on the
Computation/Output tab using the arrow keys and then pressing SET.
To Next Page
