YOKOGAWA WT5000 User Manual

16-4
IM WT5000-02EN
16.3 Configuring the IEEE 1588 Time
Synchronization
► “IEEE 1588 Time Synchronization Feature (IEEE 1588)” in the features guide
This section explains operating procedures using the following setup methods.
• Procedure Using the Setup Menu (see chapter 1)
• Procedure Using the Keys (other than SETUP) (see section 1.2 in IM WT5000-03EN)
Procedure Using the Setup Menu
1.
Tap the Setup icon , or press MENU under SETUP.
2.
Tap the Utility tab. The utility settings overview screen appears.
Pressing
ESC
closes the overview screen.
Configuring the IEEE 1588 Time Synchronization
3.
Tap System Configuration. A system setup (Date/Time, Language, LCD, Preference) appears.
Utility tab
Configure the system.
LCD
(See section 16.5.)
Language screen
(See section 16.4.)
Preference screen
(See section 16.6.)
IEEE 1588 button
Configure the IEEE 1588
time synchronization
