YOKOGAWA WT5000 User Manual

8-10
IM WT5000-02EN
8.5 Saving Numeric Data, Waveform Data, and
Screen Images
► “Conditions for Saving Numeric Data” in the features guide
► “Conditions for Saving Screen Images” in the features guide
► “Saving (Save Exec, EXEC)” in the features guide
This section explains operating procedures using the following setup methods.
• Procedure Using the Menu Icons (see page iii)
• Procedure Using the Keys (other than SETUP) (see section 1.2 in IM WT5000-03EN)
CAUTION
While data is being save, the storage device is constantly being accessed, even though the
icon that indicates this is not displayed. Do not remove the USB memory device or turn the
power off. Doing so may damage the storage device or corrupt its data.
French
ATTENTION
Pendant la collecte, le système a constamment accès au support de stockage, même si l’icône
qui l’indique n’est pas affichée. Ne retirez pas le support de stockage USB et ne coupez pas
l’alimentation. Vous risqueriez d’endommager le support de stockage ou les données qu’il
contient.

YOKOGAWA WT5000 Specifications

General

Frequency Range	DC, 0.1 Hz to 1 MHz
Number of Channels	Up to 7
Interfaces	USB, Ethernet, GP-IB, RS232
Sampling Rate	10 MS/s
Harmonic Analysis	Up to the 500th order
Weight	Approximately 15 kg
Display	10.1-inch WXGA (1280 x 800) TFT LCD
