15-5
IM WT5000-02EN
15.3 Accessing the Instrument from a PC (FTP
Server)
► “FTP Server (FTP/Web Server)” in the features guide
This section explains operating procedures using the following setup methods.
• Procedure Using the Setup Menu (see chapter 1)
• Procedure Using the Keys (other than SETUP) (see section 1.2 in IM WT5000-03EN)
Procedure Using the Setup Menu
1.
Tap the Setup icon , or press MENU under SETUP.
2.
Tap the Utility tab. The utility settings overview screen appears.
Pressing ESC closes the overview screen.
3.
Tap Network. An Ethernet setup screen (TCP/IP, FTP/Web Server, Net Drive, SNTP) appears.
Configuring the FTP Server (FTP Server)
4.
Tap FTP/Web Server. An FTP/Web Server screen appears.
Utility tab
Configure the Ethernet.
Configure the FTP server.
Set the user name (up to 32 characters).
Set the password (up to 32 characters).
Applies the settings
Set the timeout (30s to 3600s).
Note
• If you set the user name to “anonymous,” you can connect to the instrument without entering a password.
• You can also display the utility settings overview screen by moving the cursor on the Utility tab using the
arrow keys and then pressing SET.
FTP Client Software
Start an FTP client on a PC.
Enter the user name and password that you entered on the screen shown above to connect to the
instrument.
Procedure Using Keys
See section 15.2.
To Next Page
