YOKOGAWA WT5000 User Manual

2-29
IM WT5000-02EN
2.9 Setting the Crest Factor
► “Crest Factor (Crest Factor)” in the features guide
This section explains operating procedures using the following setup methods.
• Procedure Using the Setup Menu (see chapter 1)
Procedure Using the Setup Menu
1.
Tap the Setup icon , or press MENU under SETUP.
2.
Tap the Input (Advanced/Options) tab. An input settings (advanced/options) overview screen
appears.
Pressing ESC closes the overview screen.
Crest factor (Crest Factor)
3.
Tap Range. A setup screen appears for common measurement range items.
Input (Advanced/Options) tab
Range button
Set the crest factor (CF3, CF6, CF6A).
Note
You can also display the input settings (advanced/options) overview screen by moving the cursor on the
Input (Advanced/Options) tab using the arrow keys and then pressing SET.

YOKOGAWA WT5000 Specifications

General

Frequency Range	DC, 0.1 Hz to 1 MHz
Number of Channels	Up to 7
Interfaces	USB, Ethernet, GP-IB, RS232
Sampling Rate	10 MS/s
Harmonic Analysis	Up to the 500th order
Weight	Approximately 15 kg
Display	10.1-inch WXGA (1280 x 800) TFT LCD
