16-7

IM WT5000-02EN

16.5 Setting the Screen Brightness and Turning the

Screen Off

► “LCD (LCD)” in the features guide

This section explains operating procedures using the following setup methods.

• Procedure Using the Setup Menu (see chapter 1)

• Procedure Using the Keys (other than SETUP) (see section 1.2 in IM WT5000-03EN)

Procedure Using the Setup Menu

Tap the Setup icon , or press MENU under SETUP.

Tap the Utility tab. The utility settings overview screen appears.

Pressing ESC closes the overview screen.

Setting the Screen Brightness and Turning the Screen Off (LCD)

Tap System Configuration. A system setup (Date/Time, Language, LCD, Preference) appears.

Utility tab

Configure the system.

Preference screen

(See section 16.6.)

Language screen

(See section 16.4.)

Turns off the LCD backlight (you can turn

on the backlight by pressing any key)

Sets the automatic turning off of the

LCD backlight (OFF, ON)

Set the auto-off time

(1min to 60 min).

Set the LCD backlight

brightness (1 to 10).

Set the grid intensity (1 to 8).

Note

You can also display the utility settings overview screen by moving the cursor on the Utility tab using the

arrow keys and then pressing SET.

Procedure Using Keys

See section 16.1.
