Accessories
103
Figure 49 Replace Cover
NOTE: Do not install the target cover until you are sure that you do not need to remove the front cover
again.
3. Insert bar code target cover.
4. Push target cover into front cover until it snaps into place.
Figure 50 Replace Target Bar Code Cover
System Cabling
There are some general limitations that must be taken into account when designing a dispenser and
ordering hardware elements of a Personal Shopper system:
• No more than six cradles can be powered off each leg of the “Y” power cable.
MC18 Product Reference Guide.book Page 103 Tuesday, June 30, 2020 9:07 PM
