Specifications
147
Cable Specifications
Power Supply Cable, Y-type
The 16 AWG wire should have the following specifications: UL1007, 300 Volt, PVC, -40° C to 80° C
operating temperature.
Cradle Interconnection Cable
The 16 AWG wire should have the following specifications: UL1007, 300 Volt, PVC, -40° C to 80° C
operating temperature.
Table 23 Wire Run List & Specifications
Wire Color AWG
Connector 1
Molex 39-01-2060
housing; 4x,
39-00-0211
contacts
Connector 2
Molex 39-01-2025
housing; 2x,
39-00-0211
contacts
Connector 3
Molex 39-01-2025
housing; 2x,
39-00-0211
contacts
Function
Red 16 1 1 (+) term
Black 16 6 2 (-) term
Red 16 2 1 (+) term
Black 16 5 2 (-) term
Table 24 Wire Run List & Specifications
Wire Color AWG
Connector 1
Molex 39-01-2025
housing; 2x,
39-00-0211 contacts
Connector 2
Molex 39-01-2025
housing; 2x,
39-00-0211 contacts
Function
Red 16 1 1 (+) term
Black 16 2 2 (-) term
