Accessories
102
Figure 47 Daisy-Chaining Cradles
5. Use plugs to cover un-used cable outlets.
Figure 48 Cable Hole Plug Installation
Assembly
1. Replace cover.
2. Secure cover with screws.
Interconnect Cable 25-66431-01R
MC18 Product Reference Guide.book Page 102 Tuesday, June 30, 2020 9:07 PM
