Figure 45 Overall Depth of Cradle
Wiring
NOTE: During installation, ensure all interconnect cables are fully enclosed within the power supply or
cradle enclosure.
1. Install power supply, including AC line cord and power cable, into Decorative Housing.
Depth of cradle:
99 mm
(3.9”)
