Zebra PS20 Product Reference Guide

Accessories
97
Installation of the Single Slot Cradle
Installation of the Single Slot Cradle include the following mounting steps:
• Select the charging mode (see Charging Modes on page 97).
• Mount the Single Slot Cradles on a dispenser wall (see Mounting the Single Slot Cradle on a Dispenser
Wall on page 98).
• Connect the wires to the cables (see Wiring on page 100).
• Set the cradle(s) (see Controlling the Cradle on page 57).
Charging Modes
Single Slot Cradles can be installed in the following charging modes:
• Standard charging
• Fast charging
There are some general charging considerations that must be taken into account when designing a
dispenser and ordering hardware elements of a system:
Standard Charging Mode
• In standard charging mode, no more than 12 cradles can be powered off of one power supply unit (p/n
PWR-BGA12V108W0WW) using “Y” power cable CBL-DC-392A1-02.
• In standard charging mode, the current draw by each docked PS20 can reach a maximum of 1A.
AC Line Cord 50-16000-219R AC Line Cord, 1.8 meter, grounded three
wire, BS1363 plug. Associated countries:
Hong Kong, Iraq, Malaysia, Singapore,
United Kingdom.
AC Line Cord 50-16000-220R AC Line Cord, 1.8 meter, grounded three
wire CEE 7/7plug. Associated countries:
Europe, Abu Dhabi, Bolivia, Dubai, Egypt,
Iran, Russia, Vietnam.
AC Line Cord 50-16000-257R AC Line Cord, 1.8 meter, grounded three
wire, IEC 60320 C13 plug. Associated
Country: China.
AC Line Cord 50-16000-669R 1.9 meter grounded three wire, BS 546 Plug.
Associated country: India.
AC Line Cord 50-16000-672R 1.9 meter grounded three wire, S132 Plug.
Associated country: Israel.
AC Line Cord 50-16000-678R 36 inch grounded three wire.
Associated country: United States
Table 16 Accessories (Continued)
Accessory Part Number Description
MC18 Product Reference Guide.book Page 97 Tuesday, June 30, 2020 9:07 PM

Zebra PS20 Specifications

General

Operating system version	11
Operating system installed	Android
Operating system upgradeable	Yes
Number of cores	8
Processor model	660
Processor family	Snapdragon
Processor frequency	2.2 GHz
Processor manufacturer	Qualcomm
RFID reader	-
Scanner type	1D/2D
Certification	WFA
Product color	Light grey
Phone function	No
Display diagonal	4 \
Display resolution	- pixels
Speakers	Mono
Number of microphones	1
Flash memory	16 GB
Internal memory	4 GB
Battery capacity	3500 mAh
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Electrostatic Discharge (ESD) protection (air)	15 kV
Electrostatic Discharge (ESD) protection (contact)	8 kV
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	5.0
Security algorithms	40-bit WEP, 104-bit WEP, EAP-GTC, EAP-TLS, EAP-TTLS, LEAP, MSCHAPv2, PEAP, TKIP, WPA, WPA-Enterprise, WPA2, WPA2-Enterprise
Quantity per pack	10 pc(s)
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	218 mm
Width	78.6 mm
Height	75 mm
Weight	290 g
