PUTTING THE INSTRUMENT INTO OPERATION
Carl Zeiss Mounting Standard Components Axio Vert.A1
48 431030-7044-001 05/2012
Rotating the Condenser in the Transmitted Light Illumination Carrier 90 Degrees
• Hold the condenser, so that it cannot move. Rotate the locking ring rightward and push it upward.
• Turn the condenser 90 degrees in the slot until it snaps into place.
• Allow the locking ring to slide downward, and turn it leftward.
3.1.8 Inserting Stop Sliders into Condensers 0.3 or 0.4 for Sliders
• Pull the dust protection slider out of the slider slot.
• Move the required slider into the condenser from the right or left and wait until it has snapped into
the desired position. (The center position corresponds to bright field and is provided with neutral-
density filters for light attenuation.) See also Section 2.6.3.
The text on the slider must be legible in upright characters, and the stops inserted must
match the condenser / objective combination.
