ZEISS 7 Troubleshooting | 7.2 Column
3. Use an hex key 1.5mm to tighten the screws.
7.2.2.4.6 Reinstalling the Gun to the Microscope
To reassemble the microscope, you need to reinstall the gun.
Parts and Tools
Can of compressed air
Prerequisite
ü
The firing unit is installed to the gun.
Procedure
1. If your microscope is equipped with a column
safety switch, check that the safety switch is
correctly lined up when you close the gun.
2. Check the O-ring and use the can of com-
pressed air to blow away any dust particles
from the column O-ring.
3. If your microscope is equipped with a column safety switch, check that the safety switch is
correctly lined up when you close the gun.
Instruction Manual ZEISS EVO | en-US | Rev. 10 | 354706-0780-006 143
