Recording
Overdubbing
36
13. Use to select FILE,
and press
.
14. Use to select the
file, and press
.
From the same project folder, select the WAV file that you
want to assign to the track.
Press
to cancel file assignment.
Track name
Name of
assigned file
NOTE
If the selected track is stereo, you can only assign a
stereo file to it. If it is mono, you can only assign a
mono file.
Files recorded in MS RAW mode cannot be assigned to
tracks 1/2.
HINT
By selecting "NONE", you can also remove an assigned
file from a track.
By selecting and playing back a mixed down file while
overdubbing new tracks, you can layer recordings
repeatedly. ( P. 54)
15
. To end overdubbing, press .
After adding a recording, the audio files assigned to the
tracks will be used when playing back and editing the
project.
Overdubbing
MULTI FILE mode only
(continued)
