Chapter 15 Anti-Virus Screens

ZyWALL 5/35/70 Series User’s Guide

306

Figure 179 Query Example Search Results

15.4 The Update Screen

The ZyWALL comes with built-in signatures created by the ZyXEL Security Response Team

(ZSRT). These are regularly updated as new intrusions evolve. Use the Update screen to

immediately download or schedule new signature downloads.

" You should have already registered the ZyWALL at myZyXEL.com (http://

www.myzyxel.com/myzyxel/) and also have either activated the trial license or

standard license (iCard). If your license has expired, you will have to renew it

before updates are allowed.
