Chapter 7 Home Networking
VMG8924-B10A and VMG8924-B30A Series User’s Guide
126
Note: The Device needs to restart to make the role change take effect.
Figure 61 Network Setting > Home Networking > 5th Ethernet Port
The following table describes the labels in this screen.
7.10 The LAN VLAN Screen
Click Network Setting > Home Networking > LAN VLAN to open this screen. Use this screen to
control the VLAN ID and IEEE 802.1p priority tags of traffic sent out through individual LAN ports.
Figure 62 Network Setting > Home Networking > LAN VLAN
Table 36 Network Setting > Home Networking > 5th Ethernet Port
LABEL DESCRIPTION
State Select Enable to use the Ethernet WAN port as a LAN port on the Device.
Apply Click Apply to save your changes.
Cancel
Click Cancel to exit this screen without saving.
