Chapter 5 Broadband
VMG8924-B10A and VMG8924-B30A Series User’s Guide
65
5.5.1 Edit 802.1X Settings
Use this screen to edit 802.1X authentication settings. Click the Edit icon next to the rule you want
to edit. The screen shown next appears.
Figure 30 Network Setting > Broadband > 802.1x: Edit
The following table describes the labels in this screen.
5.6 The WAN Status Screen
Click Network Setting > Broadband > Wan Status to open this screen. Use this screen to query
and view the historical traffic transmission rate for a WAN interface in a bar chart. N/A displays if
the specified WAN interface was disconnected at that time.
Table 13 Network Setting > Broadband > 802.1x: Edit
LABEL DESCRIPTION
Active This field allows you to activate/deactivate the authentication.
Select this to enable the authentication. Clear this to disable this authentication without
having to delete the entry.
Interface Select an interface to which the authentication applies.
EAP Identity Enter the EAP identity of the authentication.
EAP method This is the EAP method used for this authentication.
Enable
Bidirectional
Authentication
Select this to allow bidirectional authentication.
Certificate Select the certificate you want to assign to the authentication. You need to import the
certificate in the Security > Certificates > Local Certificates screen.
Trusted CA Select the Trusted CA you want to assign to the authentication. You need to import the
certificate in the Security > Certificates > Trusted CA screen.
Apply Click Apply to save your changes.
Cancel Click Cancel to exit this screen without saving.
