Chapter 6 Wireless
VMG8924-B10A and VMG8924-B30A Series User’s Guide
87
6.5 The WPS Screen
Use this screen to configure WiFi Protected Setup (WPS) on your Device.
WPS allows you to quickly set up a wireless network with strong security, without having to
configure security settings manually. Set up each WPS connection between two devices. Both
devices must support WPS. See Section 6.10.9.3 on page 102 for more information about WPS.
Note: The Device applies the security settings of the SSID1 profile (see Section 6.2 on
page 74). If you want to use the WPS feature, make sure you have set the security
mode of SSID1 to WPA2-PSK or No Security.
Click Network Setting > Wireless > WPS. The following screen displays. Select Enable and click
Apply to activate the WPS function. Then you can configure the WPS settings in this screen.
Figure 41 Network Setting > Wireless > WPS
The following table describes the labels in this screen.
Table 23 Network Setting > Wireless > WPS
LABEL DESCRIPTION
WPS Select Disabled to deactivate WPS on the Device. Otherwise, keep Disabled unselected.
Method 1 Use this section to set up a WPS wireless network using Push Button Configuration (PBC).
Connect Click this button to add another WPS-enabled wireless device (within wireless range of the
Device) to your wireless network. This button may either be a physical button on the
outside of device, or a menu button similar to the Connect button on this screen.
Note: You must press the other wireless device’s WPS button within two minutes of pressing
this button.
Method 2 Use this section to set up a WPS wireless network by entering the PIN of the client into the
Device.
