Chapter 20 VPN
VMG8924-B10A and VMG8924-B30A Series User’s Guide
222
This screen contains the following fields:
20.3 The IPSec VPN Add/Edit Screen
Use these settings to add or edit VPN policies. Click the Add New Connection button in the
Security > VPN screen to open this screen as shown next.
Table 102 Security > IPSec VPN
LABEL DESCRIPTION
Add New
Connection
Click this button to add an item to the list.
# This displays the index number of an entry.
Status This displays whether the VPN policy is enabled (Enable) or not (Disable).
Connection Name The name of the VPN policy.
Remote Gateway This is the IP address of the remote IPSec router in the IKE SA.
Local Addresses This displays the IP address(es) on the LAN behind your Device.
Remote
Addresses
This displays the IP address(es) on the LAN behind the remote IPSec’s router.
Delete Click the Edit icon to modify the VPN policy.
Click the Delete icon to delete the VPN policy.
