Getting started | 13
Phase 4: Configuring the traffic
1. Confirm that the interface hardware and software slot configurations
match.
2. Confirm the interface card settings. Page
79
3. Open the Cross Connections application and configure the cross
connections:
Download the configuration.
Confirm or modify the traffic cross connections.
Save the configuration to the terminal.
Activate the configuration.
Page
122
4. Save the configuration to disk and close the Cross Connections
application.
Page
130
5. Connect the connection of interface cables.
6. Confirm or adjust the terminal clocking for network synchronization, if
required.
7. Test that the traffic is passing over the link as configured.
8. Confirm or configure the external alarm settings in SuperVisor. Page
74
9. Setup an external alarm connection cable, if required.
10. Reset any alarms and error counters. Page
199
11. Perform traffic pre-commissioning tests (optional)
12. Complete the commissioning form (at the back of the manual) and file. Page
265
