4RF Aprisa XE - Synchronous Cable Assemblies

Interface connections | 220
Synchronous cable assemblies
Sync EIA/TIA-232 for DTE (Part number: Cab Sync 232MT)
Pin number Pin function Direction
1 Ground -
2 TXD Input
3 RXD Output
4 RTS Input
5 CTS Output
6 DSR Output
7 Circuit DCD -
8 DCD Output
15 TXC Output
17 RXC Output
18 LTST Input
20 DTR Input
24 TXCE Input
Sync EIA/TIA-232 Cable Assembly for DCE (Part number: Cab Sync 232FC)
Pin number Pin function Direction
1 GND -
2 TXD Output
3 RXD Input
4 RTS Output
5 CTS Input
6 DSR Input
7 Circuit Ground -
8 DCD Input
15 TXC Input
17 RXC Input
18 LTST Output
20 DTR Output
24 TXCE Output
