Configuring the traffic interfaces | 79
Configuring the traffic interfaces
Important: Before you can configure the traffic interfaces, the interface cards must be already
installed (see "Installing interface cards” on page 191).
Configuring each traffic interface involves the following steps (specific instructions for each interface
card follow this page).
First, specify the port settings for the Remote terminal:
1. Select Remote > Interface > Interface Summary, select the interface card and click Configure
Interface.
2. Select the port you want to configure and modify the settings, as necessary.
3. Click Apply to save the changes you have made.
Now specify the port settings for the Local terminal:
1. Select Local > Interface > Interface Summary, select the interface card and click Configure
Interface.
2. Select the port you want to configure and modify the settings, as necessary.
3. Click Apply to save the changes you have made.
Once you have done this, you will need to configure the traffic cross-connects (see "Configuring the
traffic cross connections" on page
121) for each interface card.
