Interface connections | 223
V.35 Serial Cable Assembly for DTE (Part number: Cab Sync V35MT)
Pin number Pin function Direction
A Frame Ground
B Circuit Ground
C RTS Input
D CTS Output
E DSR Output
F RLSD Output
H DTR Input
K LT Input
P
S
SD+
SD-
Input
Input
R
T
RD+
RD-
Output
Output
U
W
SCTE+
SCTE-
Input
Input
V
X
SCR+
SCR-
Output
Output
Y
AA
SCT+
SCT-
Output
Output
V.35 Serial Cable Assembly for DCE (Part number: Cab Sync V35FC)
Pin number Pin function Direction
A Frame Ground
B Circuit Ground
C RTS Output
D CTS Input
E DSR Input
F RLSD Input
H DTR Output
K LT Output
P
S
SD+
SD-
Output
Output
R
T
RD+
RD-
Input
Input
U
W
SCTE+
SCTE-
Output
Output
V
X
SCR+
SCR-
Input
Input
Y
AA
SCT+
SCT-
Input
Input
