224 Actual signals and parameters
DI2 See selection DI1.2
DI3 See selection DI1.3
DI4 See selection DI1.4
DI5 See selection DI1.5
COMM Fieldbus interface as the source for the torque limit 1/2
selection, ie, Control word 0301 FB CMD WORD 1 bit 15.
The Control word is sent by the fieldbus controller through
the fieldbus adapter or embedded fieldbus (Modbus) to the
drive. For the Control word bits, see section DCU
communication profile on page 333.
Minimum torque limit 1 is defined by parameter 2015 MIN
TORQUE 1 and minimum torque limit 2 is defined by
parameter 2016 MIN TORQUE 2.
Note: This setting applies only for the DCU profile.
7
EXT2 Value of signal 0112 EXTERNAL REF 2 11
DI1(INV) Inverted digital input DI1. 1 = value of parameter 2015 MIN
TORQUE 1 1. 0 = value of parameter 2016 MIN TORQUE
2.
-1
DI2(INV) See selection DI1(INV).-2
DI3(INV) See selection DI1(INV).-3
DI4(INV) See selection DI1(INV).-4
DI5(INV) See selection DI1(INV).-5
2014 MAX TORQUE
SEL
Selects the maximum torque limit for the drive. MAX
TORQUE
1
MAX TORQUE
1
Value of parameter 2017 MAX TORQUE 1
DI1 Digital input DI1. 0 = parameter 2017 MAX TORQUE 1
value. 1 = parameter 2018 MAX TORQUE 2 value.
1
DI2 See selection DI1.2
DI3 See selection DI1.3
DI4 See selection DI1.4
DI5 See selection DI1
.5
All parameters
No. Name/Value Description Def/FbEq
