Actual signals and parameters 249
3002 PANEL COMM
ERR
Selects how the drive reacts to a control panel
communication break.
Note: When either of the two external control locations are
active, and start, stop and/or direction are through the
control panel – 1001 EXT1 COMMANDS / 1002 EXT2
COMMANDS = 8 (KEYPAD) – the drive follows the speed
reference according to the configuration of the external
control locations, instead of the value of the last speed or
parameter 1208 CONST SPEED 7.
FAULT
FAULT Drive trips on fault PANEL LOSS (0010) and the motor
coasts to stop.
1
CONST SP 7 The drive generates alarm PA NEL LOSS (2008) and sets
the speed to the speed defined by parameter 1208 CONST
SPEED 7.
WARNING! Make sure that it is safe to continue
operation in case of a panel communication break.
2
LAST SPEED The drive generates alarm PA NE L LOSS (2008) and
freezes the speed to the level the drive was operating at.
The speed is determined by the average speed over the
previous 10 seconds.
WARNING! Make sure that it is safe to continue
operation in case of a panel communication break.
3
3003 EXTERNAL
FAULT 1
Selects an interface for an external fault 1 signal. NOT SEL
NOT SEL Not selected 0
DI1 External fault indication through digital input DI1.
1 = Fault trip on EXT FAULT 1 (0014). Motor coasts to stop.
0 = No external fault.
1
DI2 See selection DI1.2
DI3 See selection DI1.3
DI4 See selection DI1.4
DI5 See selection DI1.5
DI1(INV) External fault indication through inverted digital input DI1.
0 = Fault trip on EXT FAULT 1 (0014). Motor coasts to stop.
1 = No external fault.
-1
DI2(INV) See selection DI1(INV).-2
DI3(INV) See selection DI1(INV).-3
DI4(INV) See selection DI1(INV)
.-4
DI5(INV) See selection DI1(INV).-5
3004 EXTERNAL
FAULT 2
Selects an interface for an external fault 2 signal. NOT SEL
See parameter 3003 EXTERNAL FAULT 1.
All parameters
No. Name/Value Description Def/FbEq
