94 Control panels
How to select a parameter and change its value
Step Action Display
1. Go to the Main menu by pressing if you are in the
Output mode, otherwise by pressing repeatedly until
you get to the Main menu.
2. Go to the Parameters mode by selecting PARAMETERS
on the menu with keys and , and pressing
.
3. Select the appropriate parameter group with keys
and .
Press .
4. Select the appropriate parameter with keys and
. The current value of the parameter is shown
below the selected parameter.
Press .
5. Specify a new value for the parameter with keys
and .
Pressing the key once increments or decrements the
value. Holding the key down changes the value faster.
Pressing the keys simultaneously replaces the displayed
value with the default value.
6. • To save the new value, press .
• To cancel the new value and keep the original, press
.
MENU
EXIT
PARAMETERS
ASSISTANTS
CHANGED PAR
EXIT ENTER
00:00
LOC
MAIN MENU 1
ENTER
01 OPERATING DATA
03 FB ACTUAL SIGNALS
04 FAULT HISTORY
10 START/STOP/DIR
11 REFERENCE SELECT
EXIT SEL
00:00
LOC
PAR GROUPS 01
99 START-UP DATA
01 OPERATING DATA
03 FB ACTUAL SIGNALS
04 FAULT HISTORY
10 START/STOP/DIR
EXIT SEL
00:00
LOC
PAR GROUPS 99
SEL
9901 LANGUAGE
ENGLISH
9902 APPLIC MACRO
9903 MOTOR TYPE
9904 MOTOR CTRL MODE
EXIT
EDIT00:00
LOC
PARAMETERS
9901 LANGUAGE
9902 APPLIC MACRO
ABB STANDARD
9903 MOTOR TYPE
9904 MOTOR CTRL MODE
EXIT
EDIT00:00
LOC
PARAMETERS
EDIT
9902 APPLIC MACRO
CANCEL
SAVE00:00
PAR EDIT
[1]
ABB STANDARD
LOC
9902 APPLIC MACRO
PAR EDIT
CANCEL SAVE00:00
LOC
[2]
3-WIRE
SAVE
CANCEL
9901 LANGUAGE
9902 APPLIC MACRO
3-WIRE
9903 MOTOR TYPE
9904 MOTOR CTRL MODE
EXIT EDIT00:00
LOC
PARAMETERS
