Control panels 95
How to select the monitored signals
Step Action Display
1. You can select which signals are monitored in the Output
mode and how they are displayed with group 34 PANEL
DISPLAY parameters. See page 94 for detailed
instructions on changing parameter values.
By default, the display shows three signals.
Signal 1: 0102 SPEED for macros 3-wire, Alternate,
Motor potentiometer, Hand/Auto and PID control;
0103 OUTPUT FREQ for macros ABB standard and
Torqu e contr ol
Signal 2: 0104 CURRENT
Signal 3: 0105 TORQUE.
To change the default signals, select up to three signals
from group 01 OPERATING DATA to be shown.
Signal 1: Change the value of parameter 3401 SIGNAL1
PARAM to the index of the signal parameter in group 01
OPERATING DATA (= number of the parameter without
the leading zero), eg, 105 means parameter 0105
TORQUE. Value 0 means that no signal is displayed.
Repeat for signals 2 (3408 SIGNAL2 PARAM) and 3
(3415 SIGNAL3 PARAM).
2. Select how you want the signals to be displayed: as a
decimal number or a bar graph. For decimal numbers,
you can specify the decimal point location, or use the
decimal point location and unit of the source signal
(setting 9 [DIRECT]). For details, see parameter 3404.
Signal 1: parameter 3404 OUTPUT1 DSP FORM
Signal 2: parameter 3411 OUTPUT2 DSP FORM
Signal 3: parameter 3418 OUTPUT3 DSP FORM.
3. Select the units to be displayed for the signals. This has
no effect if parameter 3404/3411/3418 is set to 9
(DIRECT). For details, see parameter 3405.
Signal 1: parameter 3405 OUTPUT1 UNIT
Signal 2: parameter 3412 OUTPUT2 UNIT
Signal 3: parameter 3419 OUTPUT3 UNIT.
4. Select the scalings for the signals by specifying the
minimum and maximum display values. This has no
effect if parameter 3404/3411/3418 is set to 9 (DIRECT).
For details, see parameters 3406 and 3407.
Signal 1: parameters 3406 OUTPUT1 MIN and 3407
OUTPUT1 MAX
Signal 2: parameters 3413 OUTPUT2 MIN and 3414
OUTPUT2 MAX
Signal 3: parameters 3420 OUTPUT3 MIN and 3421
OUTPUT3 MAX.
3401 SIGNAL1 PARAM
CANCEL SAVE
00:00
LOC
[103]
OUTPUT FREQ
PAR EDIT
3408 SIGNAL2 PARAM
CANCEL SAVE
00:00
LOC
[104]
CURRENT
PAR EDIT
3415 SIGNAL3 PARAM
CANCEL SAVE
00:00
LOC
[105]
TORQUE
PAR EDIT
3404 OUTPUT1 DSP FORM
CANCEL SAVE00:00
LOC
[9]
DIRECT
PAR EDIT
3405 OUTPUT1 UNIT
CANCEL SAVE00:00
LOC
[3]
Hz
PAR EDIT
3406 OUTPUT1 MIN
CANCEL
SAVE00:00
LOC
0.0 Hz
PAR EDIT
3407 OUTPUT1 MAX
CANCEL SAVE
00:00
LOC
500.0 Hz
PAR EDIT
