ABB ACS850 - Torque Ref

184 Parameters
23.22 Tune damping Speed controller damping for autotune procedure, User mode
(see parameter 23.20 PI tune mode).
Higher damping results in safer and smoother operation.
0.0 … 200.0 Speed controller damping for User autotune mode. 10 = 1
24
24 Torque ref
Torque reference selection, limitation and modification
settings.
24.01 Torq ref1 sel Selects the source for torque reference 1.
Zero No torque reference selected. 0
AI1 scaled 02.05 AI1 scaled (see page 105). 1073742341
AI2 scaled 02.07 AI2 scaled (see page 105). 1073742343
FBA ref1 02.26 FBA main ref1 (see page 109). 1073742362
FBA ref2 02.27 FBA main ref2 (see page 109). 1073742363
D2D ref1 02.32 D2D ref1 (see page 110). 1073742368
D2D ref2 02.33 D2D ref2 (see page 110). 1073742369
EFB ref1 02.38 EFB main ref1 (see page 114). 1073742374
EFB ref2 02.39 EFB main ref2 (see page 114). 1073742375
PID out 04.05 Process PID out (see page 115). 1073742853
Pointer Value pointer setting (see Terms and abbreviations on page
102).
-
24.02 Torq ref add sel Selects the source for the torque reference addition. Because
the reference is added after the torque reference selection,
this parameter can be used in speed and torque control
modes.
Note: For safety reasons, this reference addition is not
applied when stop functions are active.
Zero No torque reference addition selected. 0
AI1 scaled 02.05 AI1 scaled (see page 105). 1073742341
AI2 scaled 02.07 AI2 scaled (see page 105). 1073742343
FBA ref1 02.26 FBA main ref1 (see page 109). 1073742362
FBA ref2 02.27 FBA main ref2 (see page
109). 1073742363
D2D ref1 02.32 D2D ref1 (see page 110). 1073742368
D2D ref2 02.33 D2D ref2 (see page 110). 1073742369
EFB ref1 02.38 EFB main ref1 (see page 114). 1073742374
EFB ref2 02.39 EFB main ref2 (see page 114). 1073742375
PID out 04.05 Process PID out (see page 115). 1073742853
Pointer Value pointer setting (see Terms and abbreviations on page
102).
-
24.03 Maximum torq ref Defines the maximum torque reference.
0.0 … 1000.0% Maximum torque reference. 10 = 1%
24.04 Minimum torq ref Defines the minimum torque reference.
-1000.0 … 0.0% Minimum torque reference. 10 = 1%
24.05 Load share Scales the torque reference to a required level (torque
reference is multiplied by the selected value).
-8.000 … 8.000 Torque reference scaling. 1000 = 1
No. Name/Value Description FbEq
